What Are Geomembranes？

Leaks, fines, and remediation costs—sound familiar? The right geomembrane liner protects your budget and your reputation. Ready to specify with confidence?

Geomembranes are engineered, low-permeability polymer sheets used as barriers. A complete geomembrane liner system combines material, thickness, seams, and subgrade to control fluid migration in landfills, mining, water features, and secondary containment—delivering durable, verifiable compliance.

Below, you’ll clarify what a geomembrane lining system includes, how to choose the best geomembrane liner material, and how installation/CQA convert rolls into a compliant geomembrane lining. Keep this as your buyer’s checklist.

What is a geomembrane liner system?

You need a barrier that performs—not just plastic. A geomembrane lining system integrates layers and QA/QC to stop leaks under real-world loads.

A geomembrane liner system is a designed assembly: subgrade, cushions, geomembrane, drainage/composites, anchors, and documented QA/QC. Each layer manages stress, puncture, flow, and verification to guarantee containment

System components that actually control risk

• Prepared subgrade: Smooth, compacted, free of protrusions; prevents point loads.
• Cushion/protection (typically geotextile): Improves puncture resistance under angular aggregates.
• Primary membrane: The liner geomembrane (HDPE/LLDPE/PVC/PP/EPDM) provides the low-permeability barrier.
• Drainage/collection: Geocomposites or granular layers relieve head pressure and collect leachate/solutions.
• Anchorage: Perimeter trenches/structures resist uplift, sliding, and thermal movement.
• CQA & documentation: Verifies that your geomembrane lining system was built as specified.

Performance drivers to design in

• Puncture & interface friction for slopes and ballast.
• Chemical compatibility with leachate/fuel/solutions.
• Thermal movement & settlement accommodations.
• Seam integrity proven by testing (see later section).

Components vs. function (quick map)

Layer/Element	Primary Function	Typical Checks
Subgrade (graded, compacted)	Support, smoothness	Density, proof-rolling, visual
Geotextile cushion	Puncture mitigation	Mass/area, CBR puncture
Geomembrane liner product	Barrier (low permeability)	Resin grade, thickness, defects
Geocomposite drain	Head control, flow	Permittivity, transmissivity
Anchor trench/structures	Restraint	Embedment, backfill quality
CQA	Verification, traceability	ITPs, as-builts, test records

Use the phrase “geomembranes/ liner options” in specs to clearly indicate barrier scope and alternates. If stakeholders use Spanish, reference “geomembrana liner” for clarity across documents.

---

Which geomembrane liner material should you choose?

Different resins solve different problems. Choose by chemistry, temperature, UV, mechanics—not habit or lowest price

Common resins: HDPE (stiff/chemical-resistant), LLDPE (flexible), PVC (conforming), PP (hot-liquid tolerance), EPDM (elastic). Match resin, thickness, and texturing to containment chemistry, slopes, and settlement.

Materials at a glance (strengths and trade-offs)

Geomembrane liner material	Typical Thickness (mm)	Key Strengths	Considerations	Typical Uses
HDPE	1.0–3.0	Chemical resistance, durability, cost	Stiffer; needs careful subgrade; thermal shrink	Landfills, heap leach, secondary containment
LLDPE	0.75–2.0	Flexibility, settlement tolerance	Slightly lower chemical/UV than HDPE	Ponds, canals, flexible basins
PVC (plasticized)	0.5–2.0	Conformability, easy seaming	Plasticizer migration, compatibility checks	Water features, decorative ponds
PP (homopolymer/CSPE)	1.0–2.0	Elevated temp/chemistry options	Specialist welding, sourcing	Process ponds, hot liquids
EPDM	1.0–2.0	Elasticity, field detailing	Seaming systems differ; slower production	Decorative/irregular shapes

For procurement clarity, specify “geomembrane liner product: HDPE, 1.5 mm, textured one side, roll width X, meets project standard.” Include allowable alternates (e.g., LLDPE liner geomembrane) with performance equivalence.

Textured vs. smooth

• Textured improves interface friction on slopes, reduces slippage risk.
• Smooth offers easier deployment and may suit flat basins.

Thickness selection cues

• Higher traffic, coarser ballast, steeper slopes → thicker membranes and cushion geotextiles.
• Chemical exposure or hydrocarbons → HDPE/PP with proven compatibility.

Quick selection table: purpose → material

Purpose	Preferred Option	Why it works
Landfill basal liner	HDPE 1.5–2.0 mm (textured)	Chemical resistance + slope friction
Mining heap leach	HDPE 1.5–2.0 mm (textured)	Aggressive solutions + stacking loads
Decorative pond/canal	LLDPE/PVC 1.0–1.5 mm (smooth)	Conformability, detailing ease
Hot/process fluids	PP variants 1.5–2.0 mm	Temperature/chemical tolerance
Irregular shapes	EPDM/LLDPE	Elasticity and field detail flexibility

---

How are liner geomembranes installed and verified?

Shortcuts here cost you later. Controlled welding and testing turn polymer rolls into a watertight system.

Crews prepare subgrade, deploy panels, weld seams (hot wedge/extrusion), and verify with non-destructive and destructive tests. Strong CQA proves your geomembrane lining service delivered compliance.

Field workflow you should expect

1. Subgrade readiness: Smooth, compacted, no protrusions; repair soft spots.
2. Deployment plan: Panel layout to minimize T-joints; manage thermal expansion.
3. Seaming:

• Hot-wedge for linear seams (dual-track for air-channel testing).
• Extrusion for details/repairs/fillets.

1. Detailing: Penetrations, sumps, boots, and terminations; avoid wrinkle-in-seam.
2. Anchorage: Proper embedment in trenches; backfill sequence controls movement.

Testing that protects you

• Non-destructive: Air-channel (dual seams), vacuum box, spark testing where specified.
• Destructive: Peel and shear coupons at set frequencies; track results by panel and seam ID.
• Post-construction: Electric leak location (ELL) to pinpoint holidays before covering.

Installation & verification matrix

Control Step	Method	Acceptance Intent
Dual-track hot-wedge seam	Air-channel pressure decay test	Continuity and airtightness of seam path
Extrusion welds	Vacuum box over soap solution	No bubbles/leaks
Daily seam coupons	Field peel & shear tests	Meets strength % of parent sheet
Documentation (CQA)	ITPs, logs, as-builts, traceability	Transparent, auditable installation record
Final integrity check	ELL (water puddle/ARC/bridge)	Locate/repair pinholes before cover

A competent geomembrane lining service will hand you complete CQA packages: welder settings, ambient data, seam maps, test results, repair logs, and as-built drawings. This is your warranty’s backbone.

Conclusion

Select the right geomembrane liner, build a complete lining system, and verify with CQA—so your containment performs, passes audits, and lasts.
